Raycus Lazer Source 50W Technical parameters |
|
Model | RFL-P50Q |
Average output power(W) | 50 |
Output Power Tunability(%) | 10-100 |
Wavelength(nm) | 1064 |
Repetition Frequency Range | 20-60 |
Output Power Stability | <3% |
Output Beam Diameter(mm) | 7+/-1 |
Beam Quality(M2) | <1.5 |
Pulse width (ns) | 90-120 |
Polarization State | Random |
Pulse width(ns) | <130@20kHz |
Single Pulse Energy(mJ) | 1.0@20kHz |
Delivery Cable Length(m) | 2 |
Power supply | DC24V |
Power consumption(W) | 170 |
Dimensions(mm) | 260*391*120 |
Cooling | air cooler |
Operating Temperature Range(°) | 0-40 |
